Features That Makes TS5 Stand Out
Multiple Clamping Styles, Upgradable and Interchangeable
Game-Changing、Ultimate Creativity
Soive 99% of the Mugs Engraving Problems on the Market
Discover What's New
Pre-assembled 95%
Magnetic Closure Design
Safety and Eye Protection
Dust and Smoke Exhaust
Compatible With Mainstream Software
Special Filtering Material to Effectively Block Harmful Blue Li
Unleash Software Flexibility
Satisfy all Your Creativity From Start to Advanced,Compatible with Lightburn and so on
Product
Specifications
Main material
Aluminum + High Carbon Steel
Net weight
9.13 kg
Gross weight
10.55 kg
Chuck external clamping range
Ø26 – Ø140 mm
Chuck internal clamping range
Ø15 – Ø110 mm
Chuck tilt adjustment angle
-8° to +8°
Product dimensions
480 × 200 × 298 mm
Working area
249 × 123 × 123 mm
Package dimensions
553 × 280 × 387 mm
Input voltage
100-240V~50/60Hz
Output voltage
24V
Laser power
7W
Overall power
60W
Wavelength
450 ± 5 nm
Spot size
0.035 × 0.1 mm
Supported
TF Storage Card,USB Port,Wi-FiReturn to Origin After Engraving,Motion Control,Laser Power Adjustment,External Exhaust Interface
Not supported
Bluetooth, Limit Homing,Power-Off Resume
Optional
Gas Assist, Screen Control
Engraving materials
Mugs,Wine Glasses,Stainless Steel,Rings
Motion structure
XY dual-axis
X/y axis positioning accuracy
0.1mm
Maximum speed
10,000 mm/min
Engraving software
LaserGRBL(Windows), LightBurn(Common)
Supported operating systems
macOS / Windows / Linux
Software languages
Chinese, English, Spanish, German, French, Russian, Portuguese, Italian, Japanese, Korean, etc.
Supported software formats
lbrn,BMP,JPG,PNG,GCODE
Engraving file format
.nc
Safety certifications
CE\FCC\ROHS CE-EMC, CE-LVD, CE-RED, CE-MD, EN60825-1,EN60825-4, ROHS, IEC60825, FCC-Sdoc, FCC-ID, FDA
Operating temperature
5℃ ~ 40℃
Operating humidity
20% ~ 60% RH
