CNC Series

TTC450

Machine Cannot Connect to Computer, How to Handle?
  1. Ensure that the machine is turned on.
  2. Make sure the USB cable is connected to the machine’s port.
  3. Check if the computer can recognize the machine’s COM signal. (Or try inserting it into a different port on the computer)
  4. If no new COM is seen in the previous step, it is necessary to install a CH340 driver. It can be obtained from the TF card files. Alternatively, install the CH340 driver through the lasergrbl tools.
  5. Set the correct baud rate, 115200;
  6. Select the correct “COM” port in the software. (You can try every COM port)
  7. Click to connect.
  8. If the above steps still cannot connect, please restart your computer and then re-execute steps 5-7. (There may be software conflicts)
  9. If it still fails and there is a prompt message in the left dialog box of the software, you need to update the firmware. Then redo the above steps.
  10. If you cannot connect and control the machine with candle, but you can with easle or GRBL and other software, it indicates that there is a problem with the candle installation package. Please completely uninstall and go to the candle official website to download and reinstall.
The motor is not working.How to deal with it?
  1. Ensure that the machine has successfully connected to the computer’s Candle software. If it does not connect successfully, you cannot control the motor to operate.
  2. Check if the motor cables are installed correctly. If in doubt, try re-installing them.
  3. If some of the motors work normally, open the control box, find the main control board, and try to swap the motor cables inside the control box. If they still do not work after swapping, it may be that the cables have problems, please inform us for replacement.
  4. If the motor vibrates but does not move, it may be that the cable sequence is problematic. You can use a tool with a sharp corner to swap the order of the two central wires.
  5. After swapping the cable order, if the direction is incorrect, you can try swapping the order of the two adjacent wires on the left.
  6. If after the above steps, the originally normal motor also does not work, it may be that the driver of the main control board is damaged. Please inform us for replacement. When informing, providing a video will help us confirm the problem and replace the new parts.
The machine makes a strange noise. How to deal with it?

May be caused by the following two situations:

  1. Exceeding the machine’s working travel.
    Please try the following operations: Set the software parameters according to the machine’s nominal working size. The working range of TTC450 is 460mm * 460mm * 80mm.
  2. Transmission parts friction, please try the following operations:
Unable to turn on the machine. How to deal with it?
  1. Make sure the adapter or power cord is connected to the power source and observe whether the indicator light is on.
  2. Press the switch repeatedly, observe if there are any changes in the machine.
  3. Remove the TF memory card, then restart the machine.
  4. Unplug all the motor cables to disconnect them, then restart the machine. If the machine can start, plug the cables back in one by one. When the machine shuts down again, it may be that the plugged cable has a problem.
  5. Open the control board box, check if there is any detachment of the switch wire.
  6. Try using another adapter of the same specification.
Machine Moves Incorrect Distance, How to Handle?

After successfully connecting the software and the machine, please follow these steps:

  1. Enter $$ in the control bar to bring up the parameter page.
  2. Find the parameters $100, $101, and $102.
  3. Check if all three values are set to 800.
  4. If any of the values are not 800, change them to 800.
Machine Axis Moves in the Opposite Direction, How to Handle?

After successfully connecting the software and the machine, please follow these steps:

  1. Enter $$ in the control bar to bring up the parameter page.
  2. Find the parameter $3.
  3. Modify the value of $3 with the following commands:
  4. After each modification, check if the direction of each axis is correct.
  5. Try up to 6 times until the direction of each axis is correct.
Mainboard Power Switch (Angel Eye Switch) is Ineffective, Machine Cannot Start
  1. First, disassemble the mainboard control box and carefully check the wiring of the power switch to ensure that the wiring is correctly connected and there is no damage or detachment.
  2. Then, try to short-circuit the power interface on the mainboard and try to start the machine. If the machine can start normally, this may indicate that there is a problem with the power switch (Angel Eye switch), which may be damaged.

These two steps can help determine if the power switch is damaged, but if the problem cannot be solved, further inspection or replacement of the power switch may be necessary.

How to adjust the drive pulley?
  1. Remove the outer casing on both sides of the Y-axis.
  2. Adjust the eccentric nuts on both sides.
    Note: The optimal tightness should allow the pulley to rotate easily by hand while still feeling some friction.
How to adjust the parallel Y-axis motor?
  1. Cut the cable tie on the Y-axis sheet metal
  2. Move the Y axis to the origin of the compression, unplug the Y axis
  3. The other side of the Y axis can be leveled in the same way
How to Switch the 20W laser head?
  1. Remove the wiring on the spindle motor, and remove the spindle motor and fixed base.
  2. Take out the 20W laser head fixing base and install the 20W laser head on the fixing base.
  3. Remove the screen and the front cover of the motherboard box, connect the laser cable to the S-TTL-V port on the motherboard, reinstall the front cover and screen, and connect the extension cable to the laser head.
  4. Connect the machine and computer with the blue link line, open the MKSLaserTool software to erase the firmware first, and then select Firmware to brush in.
  5. Open the laserGRBL software and connect the CH340 driver to import the laser configuration. After the import, test the engraving.

TTC450 Pro

Machine Screen Shows Blue Screen (White Screen) and Cannot Operate, How to Solve?
  1. Loosen the four screws on the back of the screen, then try to power on again. If the problem returns to normal, consider adding an insulating pad when reinstalling the screws.
  2. Try to re-flash the firmware for the machine, then power on again. Check if the problem is resolved.
  3. If the above methods cannot solve the problem, please contact us, and we will replace a new screen for you.
X-Axis Sheet Metal Parts Shake, Y-Axis Motor Shafts on Both Sides are Loose
  1. The sheet metal parts behind the BOM wheel on the back have an eccentric nut installed, which may not have been adjusted properly at first, and may gradually loosen during subsequent use. Therefore, it is necessary to tighten the eccentric nut with a wrench to ensure its stability and normal operation.
  2. The motor shafts have springs in the middle, so slight looseness is a normal phenomenon, there is no need to worry too much.
Machine Can Move Normally, But the Carving Appears Blurry and Unclear

There is a brass nut behind the sheet metal parts of the X-axis position, the screws on it may be loose and need to be tightened, see the link for the picture.

Lead Screw Movement Bends and Deforms
  1. If you suspect that the lead screw is bent, separate the lead screw from other components and rotate it alone to check for any unevenness or blockages to determine if there is a problem with the lead screw bending.
  2. If you suspect that the coupling is deformed, separate the coupling from other components and check its structure and rotation alone to determine if there is a problem with the coupling deformation.
When the Screen Does Not Display
  1. Check the Ethernet cable connection: Please make sure the Ethernet cable connection is firm, if you find it loose, please retighten the connection, or try changing the order of the Ethernet cable and restart the machine.
  2. Screen line looseness: During the transportation of the machine, vibrations may occur, which may cause the internal wires of the machine to become loose, resulting in poor contact or complete disconnection. When this happens, the screen may display white and cannot work normally. Please first check if there are any issues with the lines.
  3. Mainboard or screen failure: If the Ethernet cable connection and screen line looseness issues are ruled out, and the screen still cannot display, it may be that the mainboard or screen has failed. If there are multiple machines of the same model, you can try replacing a normally displayed
    screen to the machine with a problem. If the replaced screen can display normally, then the original screen may have a problem; if it still cannot display after replacement, it may be that the mainboard has a problem. If you encounter this situation, please contact the after-sales customer service for further processing.
Mainboard Does Not Read the Card

1. SD card issue:

  • First, check if the SD card can be used normally on the computer. If it can, while backing up the files, try to format the SD card.
  • Insert the formatted SD card into the mainboard and test it with power on. If the mainboard still cannot recognize the SD card, it indicates that the SD card may have a problem, and it is recommended to replace it with a new one.

2. Check if the card slot is loose:

  • Long-term use may cause the card slot to shake, resulting in poor card reading. If you suspect that the card slot is loose, you need to replace it with a new card seat.
  • Sometimes the card may suddenly become unresponsive after being inserted for a while. You can try quickly inserting and removing the card a few times, then turn off the power, clean the card slot with alcohol, and insert the card a few more times. If it still cannot be used normally after cleaning, it may be necessary to replace it with a new card seat.
How to adjust the drive pulley?
  1. Remove the outer casing on both sides of the Y-axis.
  2. Adjust the eccentric nuts on both sides.
    Note: The optimal tightness should allow the pulley to rotate easily by hand while still feeling some friction.
How to adjust the parallel Y-axis motor?
  1. Tighten the two adjustment screws into the Y-axis profile (protruding halfway).
  2. Then control the Y-axis to move towards the front of the machine until it butts against the two adjustment screws.
How to adjust the motherboard drive voltage?
  1. Open the machine’s mainboard control box and locate the drive.
  2. Power on the machine.
  3. Use a multimeter to connect the positive probe to one side of the drive’s cross screw and the negative probe to the USB port, then check the value.
  4. The normal value should be around 0.96V. If the value is inaccurate, adjust the voltage by adjusting that cross screw.
  5. After adjustment, reinstall the mainboard control box. The linked video only demonstrates the measurement value; please refer to the above instructions for specific voltage adjustment operations.
  6. Ignore the differences of the main control board. The operations are the same
How to switch to laser mode?
  1. Remove the spindle front cover and unplug the spindle motor line.
  2. After removing the spindle fixing seat, remove the backplane of the spindle protective shell.
  3. After installing the 20W laser head holder on the Z-axis module, install the 20W laser head.
  4. Connect the laser wire to the laser head and the switching plate.
  5. Open the Settings panel of the screen and switch the mode to Laser mode.

TTC6050

How to deal with abnormal noise from the machine?

It can be caused by two things:

1.Beyond the machine’s working schedule。
Try the following: Set the software parameters according to the nominal working size of the machine

2.Drive friction, please try to do the following：

  • Turn off the power of the machine, manually move the X axis left and right, move the Y axis back and forth, and check whether there is stuck or difficult to move.
  • Test each drive component individually, including checking the drive voltage (The voltage should be within 1.35V).
  • Adjust screws or add lubricants according to the conditions of different parts to reduce friction.
When the engraving screen appears pause words for no reason?

This is because the infrared beam sensor is triggered, resulting in the machine to pause and restart the engraving, pay attention to no objects to block the infrared, you can turn on or off the security protection in the tool Settings after the engraving.

How to solve the problem of delamination when engraving is out of step?
  1. Check whether the feed unit is wrong, the unit used in the TTC6050 system is (mm/min), if the unit in the programming software is mm/s, then the set value should be multiplied by 60 for example: (The unit used by the programming software is 30/s, and it will be 30x60=1800mm/s when used on the machine), be careful not to set the feed rate too large to avoid damaging the machine.
  2. Need to check the corresponding shaft drive, whether there is overheating, you can try to reduce the feed speed to see if there is improvement.
How to install USB drivers?

Driver program name: CH340SER.EXE
Where can you find this program?

  1. It is included on the manufacturer’s TF card.
  2. Search on a browser: CH340SER or CH340 official website.
    Note: Failure to install the driver program may result in the computer being unable to connect to the machine. The driver files for Windows and macOS are different.
How to replace a 20W laser head?
  1. Unplug the power supply line of the spindle motor and the line of the searchlight, and then loosen the clamp to remove the 500W spindle motor.
  2. Remove the back fixing plate of the spindle and replace it with the fixing backplane of the laser head
  3. After installing the laser head and dovetail slider, install the dovetail chute on the adapter plate.
  4. Install the laser head on the chute, and then install the hand nut on the side.
  5. Connect the laser head conversion cable to the laser head and conversion board.
How to eplace the 6050 control box adapter board and mainboard?
  1. Loosen the screws at the end of the handle on the control box. After loosening the four fixing screws that look at the backplane, flip the control box and loosen the three fixing screws at the bottom.
  2. Pull out the fixing plate inside the control box and first take a picture of all the wiring harnesses and interfaces for a background or mark.
  3. Remove all the wiring harnesses on the adapter board, replace them with new ones, and attach the photos or marks left before the wiring installation (if you only replace the adapter board here, you can install it again according to the assembly method).
  4. The same is true for replacing the mainboard. Remove all cables, remove the mainboard, install a new mainboard, and reconnect the mainboard according to the wiring information.
  5. Finally, reinstall the fixing plate of the control box.
How to install USB drivers?

Driver program name: CH340SER.EXE
Where can you find this program?

  1. It is included on the manufacturer’s TF card.
  2. Search on a browser: CH340SER or CH340 official website.
    Note: Failure to install the driver program may result in the computer being unable to connect to the machine. The driver files for Windows and macOS are different.

TTC3018

Machine Cannot Connect to Computer, How to Handle?
  1. Ensure that the machine is turned on.
  2. Make sure the USB cable is connected to the machine’s port.
  3. Check if the computer can recognize the machine’s COM signal. (Or try plugging it into a different port on the computer)
  4. If no new COM is seen in the previous step, you need to install a CH340 driver. It can be obtained from the TF card files. Alternatively, install the CH340 driver through the LaserGRBL tools.
  5. Set the correct baud rate, 115200.
  6. Select the correct “COM” port in the software. (You can try every COM port)
  7. Click to connect.
  8. If the above steps still cannot connect, please restart your computer and then re-execute steps 5-7. (There may be software conflicts).
  9. If it still fails and there is a prompt message in the left dialog box of the software, you need to update the firmware. Then redo the above steps.
Motor Does Not Work, How to Handle?
  1. Ensure that the machine has successfully connected to the computer’s Candle software. Because if it is not connected successfully, you cannot control the motor to operate.
  2. Check if the motor cables are correctly installed. (You can try reinstalling)
  3. If there is a motor that works normally, you can open the control box, find the main control board, and swap the motor cables inside the control box. If it still does not work after swapping, it indicates that there is a problem with the cables. Please inform us to replace them.
  4. If the motor vibrates but does not move, it may be that there is a problem with the sequence of the cables. You can use a tool with a sharp corner to swap the order of the two central wires.
  5. After swapping the order of the cables, if the direction is incorrect, you can swap the order of the two adjacent wires on the left.
  6. After checking step 3, if the originally normal motor also does not work, it may be that the driver of the main control board is damaged. Please inform us to replace it. When informing us, a video would be better, as it can facilitate us to better confirm the problem and replace the new parts.
Machine Makes Unusual Noises, How to Handle?

It may be caused by the following two situations:

First Type

  1. Exceeding the machine’s working travel.
  2. Friction of the transmission parts.

Second Type

  1. Exceeding the machine’s working travel. Please try the following operations. Set the software parameters according to the machine’s nominal working size, the working range of TTC3018 is 300mmx180mm×40mm.
  2. Friction of the transmission parts. Please try the following operations.
    2.1. Turn off the machine power, move the X-axis left and right, move the Y-axis front and back, and check for any jamming or difficulty in movement.
    2.2. Test each drive part individually. Adjust the screws or add lubricant according to each different part.
Machine Cannot Start, How to Handle?
  1. Ensure that the adapter or power cord is connected to the voltage, and the indicator light is on.
  2. Press the switch repeatedly and observe the changes in the machine.
  3. Remove the TF memory card and restart the machine.
  4. Unplug all motor cables. Disconnect them and then restart the machine. If the machine can be turned on, plug the cables back in one by one. If the machine shuts down again, this cable may be damaged.
  5. Open the control board box and check: whether the switch wire is detached.
  6. Use another adapter of the same specification.
Machine Moves Incorrect Distance, How to Handle?
  1. Successfully connect the software and the machine.
  2. Enter $$ in the control bar to bring up the parameter page.
  3. Find the values $100, $101, and $102, and check if they are all 800.
  4. If any value is not 800, please change it to 800.
Machine Axis Moves in the Opposite Direction, How to Handle?
  1. Successfully connect the software and the machine.
  2. Enter $$ in the control bar to bring up the parameter page.
  3. Find the value $3 and modify it according to $3=0, $3=1, $3=2, $3=3, $3=4, $3=5.
  4. After each modification, check whether the direction of each axis is correct. After a maximum of 6 attempts, we can correctly modify the direction.
Machine Restarts the Mainboard or Software Disconnects When Engraving?
  1. Mainboard firmware error, causing a large instantaneous power when the main spindle motor and stepper motor start at the same time, and the adapter power cannot keep up.
    Solution: Use the flashing firmware to update the mainboard firmware again. (Please ignore the differences in the model, the writing method is the same)
  2. Some materials have a high density, and for the machine’s main spindle, it needs to increase its speed and increase the feed amount.
Motion Path is Normal, But the Drill Does Not Rotate?
  1. The main spindle motor line is connected correctly.
  2. Check if the motor line on the mainboard is plugged in properly.
  3. Whether the main spindle rotation is turned on in the software.
  4. Measure the voltage at the main spindle motor interface on the mainboard (measure when the main spindle is turned on, no voltage or insufficient voltage may indicate that the mainboard is broken).
  5. Test with other cables, as the cable may be damaged.
  6. If there is no problem with the above, it may be that the main spindle motor itself is damaged.

TTC-H40/H80

What are the technical specifications of the TTC-H40 CNC engraving machine?

The TTC-H40 is a high-performance desktop CNC engraving machine with a 1m x 1m machining platform and independent X, Y, and Z axis control. Equipped with high-precision stepper motors, precision ball screws, and trapezoidal lead screws, it ensures exceptional machining accuracy and repeatability.

What are the maximum engraving speed and acceleration of the TTC-H40?

The TTC-H40 has a maximum engraving speed of 1800 mm/min and an acceleration of 500 mm/s². These parameters ensure the machine's stability and efficiency during high-speed processing.

What file formats does the TTC-H40 support?

The TTC-H40 supports G-code and .nc formats.

What are the features of the TTC-H40 control system?

The TTC-H40 utilizes an advanced control system with a multilingual user interface, spindle power-off function, and real-time progress display, ensuring operational safety and machine reliability.

What are the tooling options for the TTC-H40?

The TTC-H40 is equipped with a variety of tool types, including pointed cutters, double-edge straight groove milling cutters, and helical milling cutters, to accommodate diverse machining needs.

What are the electrical components and drive system of the TTC-H40?

The TTC-H40 utilizes high-quality electrical components and drive systems, including integrated adapter boards and drivers, ensuring high performance and long-term stability.

How does the TTC-H40 calibrate its tool setting?

The TTC-H40 is equipped with a tool setter, which performs tool calibration before engraving to ensure optimal processing accuracy.

What safety features does the TTC-H40 include?

The TTC-H40 is equipped with multiple safety features, including an emergency stop button, overload protection, limit switches, and a spindle power cutoff, to ensure operator and machine safety.

What maintenance and servicing requirements does the TTC-H40 require?

The TTC-H40 requires regular maintenance and servicing, including cleaning dust, lubricating the lead screw and optical axis, and inspecting worn parts to maintain optimal performance and extend its lifespan.

Accessory assembly tutorial

500w Spindle Motor

Installed on TTC450

Installed on TTC450 Pro

4th Axis Rotary Module
30000RPM Wood Router

Install on TTC450Pro

  1. Open the motor cover first, then unplug the motor wires and remove the 775 motor.
  2. After removing the back panel, disassemble the clamps.
  3. Dismantle the trimming machine’s accessory clamps, install the clamp base, and then lock the fasteners.
  4. Place the trimming machine into the clamps and secure it tightly, then take out the adapter and connect the aviation plug.
  5. After connecting the adapter to the power source, connect the control wire to the 24V port located below the screen.

Install on TTC450

  1. Install the extension cable provided in the kit onto the control wire, and then connect it to the input line of the spindle.
Vacuum Cleaner Monster (M1) Kit

Install on the 775 spindle.

  1. Remove the tool head cover and install the spindle (it may be easier to take off the clamp along with the spindle for installation), which requires two screws.
  2. Remove the brush cover and install the brush, then snap the base cover back into place.
  3. Open the vacuum cleaner’s top cover and remove the hose and storage bag.
  4. Open the vacuum cleaner’s top cover and remove the hose and storage bag.
  5. Attach one end of the hose to the vacuum cleaner, and the other end to the tool head.
  6. Connect the USB cable to the vacuum cleaner, secure the cable along the hose with a cable tie, and plug the other end into the tool head.
  7. Connect the vacuum cleaner to the power source.
  8. 8.Turn on the automatic vacuuming function.
  9. Turn on the LED light.
  10. Manual activation.

Install on the 500W spindle.

  1. Install on the 500W spindle with a slight difference; the clamp along with the spindle can be removed for installation, requiring four screws.
500W Air-Cooled Cooling Kit

This is the installation tutorial for machines of TTC6050 and above. Earlier models require the use of hose clamps. The difference can be seen at the end of this tutorial

  1. Align the air nozzle with the air outlet of the fan and install it
  2. Fix the air nozzle with the machine screw
  3. Install the air-cooled component on the hole position in the red frame on the side of the spindle fixture
  4. Manually adjust the air nozzle to align with the tip of the knife
  5. Connect the power cord to the interface at the back of the fan
  6. Just adjust the speed control knob in front of the fan to dissipate heat

Models such as TTC450 and TTC450Pro can be installed at the positions indicated by the hose clamps in the picture.

Laser Engraver

TTS-55 Pro

How to Solve the Problem of Not Being Able to Engrave Metal?
  1. Material Confirmation:
    Please ensure that the metal material used is appropriate, and avoid using untreated aluminum. As a highly reflective material, aluminum may not be suitable for some laser processing processes.
  2. Laser Head Focus Calibration:
    Please carefully check whether the focus of the laser head has been correctly adjusted. The accuracy of the focus is crucial for the quality and precision of laser processing.
  3. Software Configuration File Check:
    Please confirm whether the software has successfully imported the required configuration file. Correct importation of the configuration file is a prerequisite for ensuring the normal operation of the laser equipment.
  4. Power Setting Review:
    If the configuration file has been imported, please further check whether the power setting has been set to the maximum value, that is, 1000. The correct power setting is very critical for achieving the best laser processing effect.
How to Solve the Problem of Not Being Able to Engrave Wood or Cardboard?
  1. Material Confirmation:
    Firstly, please confirm whether the wood and cardboard materials you have selected are suitable for laser engraving. Different materials have varying adaptability to laser engraving, so understanding the material properties is the first step to ensure the engraving effect.
  2. Spot Check:
    Before starting the engraving, please check whether the size of the laser spot meets the engraving requirements. The size of the spot directly affects the precision and detail of the engraving.
  3. Software Parameter Adjustment:
    Please carefully check and adjust the speed and engraving power settings in the software to ensure they are at the appropriate level. Reasonable speed and power settings are crucial for achieving high-quality engraving results.
  4. Laser Head and Chip Inspection:
    If problems are encountered during the engraving process, such as the inability to engrave cardboard, it may be necessary to inspect the attenuation of the laser head or whether the internal chip is damaged. These factors can affect the quality and effect of the laser engraving.
How to Solve the Issue of the Laser Head Not Emitting Light?

1. Laser Head Connection Inspection:

  • Please first check whether the wiring of the laser head is loose or incorrectly connected.
  • If you find that the cable is loose or improperly connected, please reconnect it immediately to ensure the normal operation of the laser head.

2. Laser Head and Fan Function Check:

  • After starting the machine, observe whether the fan on the laser head is rotating normally.
  • At the same time, check whether the signal light on the laser head lights up when the laser is turned on (the signal light color may be blue or green depending on the model).
  • If the fan is rotating and the signal light is on, but the laser head is not emitting laser light, this may indicate that there is a problem with the laser head and it needs to be replaced.
  • Additionally, if the fan of the laser head does not rotate, but the power supply from the mainboard port is normal, then the problem may lie in the wiring or the laser head itself, which requires further inspection or replacement.
How to Deal with the Machine Not Connecting to the Computer?

1. Power On Check:

  • Ensure that the laser engraving machine is powered on and that the fan of the laser module is rotating to confirm that the machine is working properly.

2. USB Connection Confirmation:

  • Please confirm that the USB cable is correctly connected to the machine’s interface.

3.Computer Recognition Check:

  • Check if your computer can recognize the machine’s COM port signal. If necessary, try using another USB port on the computer.

4. Driver Installation:

  • If no new COM port was detected in the previous step, you may need to install the CH340 driver. You can obtain this driver from the TF card files or install the CH340 driver through the lasergrbl tool.

5. Baud Rate Setting:

  • Set the correct baud rate in the software, usually 115200.

6. Port Selection:

  • Select the correct COM port in the software. If you are unsure, try each available COM port.

7. Connection Operation:

  • Click the “Connect” button in the software to establish communication with the machine.

8.Troubleshooting:

  • If you still cannot connect after the above steps, restart your computer and repeat steps 5 to 7 without opening any other software. This helps to rule out the possibility of software conflicts.

9.Firmware Update:

  • If all steps have been tried and it still fails, and the software displays a prompt message on the left side of the dialog box, you may need to update the machine’s firmware. After updating the firmware, repeat the above steps.

Update Firmware Video Link

How to Deal with the Motor Not Working?

1. Connection Confirmation:

  • Ensure that the laser engraving machine has been successfully connected to the laserGRBL software on the computer. If the connection is not successful, you will not be able to control the motor’s operation.

2. Motor Cable Inspection:

  • Check whether the motor cables have been correctly installed. If unsure, it is recommended to try reinstalling the cables.

3. Control Box Motor Cable Swap:

  • If there are other motors that work normally, you can open the control box and locate the main control board, then try swapping the motor cables inside the control box.
  • If the motor still does not work properly after the swap, this may indicate that there is an issue with the cables. Please notify us, and we will send you replacement cables.

4. Cable Sequence Adjustment:

  • If the motor vibrates but does not move, it may be a problem with the cable sequence. You can use a tool with a pointed end to try swapping the order of the two middle wires.

5. Cable Order and Motor Direction Adjustment:

  • After swapping the cable order, if the motor direction is incorrect, you can try swapping the order of the two adjacent wires on the left.

6. Main Control Board Driver Inspection:

  • If, after completing all the checks in step 3, the originally normal motor also stops working, it may be that the driver on the main control board is damaged. Please notify us in time, and we will send you a replacement driver.

7. Problem Reporting:

  • When reporting a problem to us, it is best to provide a video explanation, which will help us more accurately identify the problem and provide the corresponding replacement parts.

Graphic link

How to Deal with the X-axis Not Being Parallel (Tilted)?

1. Motor Function Test:

  • First, conduct a functional test on the motors on both sides. Disconnect the wiring of one side motor and use the software to control the Y-axis to move twice to confirm whether the motor can work properly.

2. Eliminate Motor Issues:

  • If the test results indicate that there is no problem with the motor, then please loosen the fixing screws on both sides of the X-axis guide rail.

3. Sled and Guide Rail Inspection:

  • Check whether the wheels of the left and right sleds are in close contact with the aluminum guide rail and operate smoothly without obvious shaking.
  • If the wheels are not in contact or there is shaking, use a wrench to adjust the hexagonal column to ensure that the sled wheels are in close contact with the guide rail.

4. Sled Positioning and Fixation:

  • Align the left and right sleds on the aluminum rail with the same scale markings.
  • Tighten the screws again to fix the sleds and ensure their positions on the guide rail are accurate.

5. Synchronous Belt Tension Adjustment:

How to calibrate the focus before engraving?

Focus adjustment before carving:

  1. Confirm the focus position: - Before starting to carve, it is necessary to ensure that the laser focus is located on the surface of the carved object to obtain the best engraving effect.
  2. Using a fixed focus column: - Using a fixed focus column as an auxiliary tool can help you adjust the focus more precisely.
  3. Place the fixed focus column: - Place the fixed focus column between the carved object and the adjustment block of the machine, ensuring that it is stable and in the correct position.
  4. Adjust the Z-axis lifting module: - Rotate the Z-axis lifting module and carefully adjust the height of the laser head until the laser module exactly touches the first step of the fixed focus column.

Precautions:

  • During the adjustment process, handle with gentleness and precision to avoid any damage to the laser head or the object being engraved.

-Focusing video

How to calibrate the focus before cutting (be careful of collision to avoid damaging the laser housing)?

Focus Adjustment Before Cutting:

1. Determine the Focus Position：

  • Before cutting, the focus must be precisely positioned in the middle of the cutting object’s stratum to ensure the quality and accuracy of the cut.

2. Adjust the Focus According to Material Thickness：

  • Based on the varying thickness of the material, the focus height should be set accordingly to meet different cutting requirements.

3. Use a Fixed Focus Post for Assisted Adjustment：

  • Use a fixed focus column as an auxiliary tool to help you adjust the position of the Z-axis more accurately.

4. Settings for Different Thicknesses：

  • Assuming the thickness of the engraving object is 2mm, use the second step of the fixed focus column for focus setting.
  • If the object thickness is 4mm, use the third step of the fixed focus column for focus setting.
  • For objects that are 6mm thick, use the fourth step of the fixed focus column to set the focus.

5. Rotate the Z-Axis Lift Module：

  • Based on the selected focus column step, rotate the Z-axis lift module to precisely adjust the height of the laser head until the correct focus position is achieved.

TTS-10 Pro

How to Deal with the Machine Not Connecting to the Computer?

1. Power On Check:

  • Ensure that the laser engraving machine is powered on and that the fan of the laser module is rotating to confirm that the machine is working properly.

2. USB Connection Confirmation:

  • Please confirm that the USB cable is correctly connected to the machine’s interface.

3.Computer Recognition Check:

  • Check if your computer can recognize the machine’s COM port signal. If necessary, try using another USB port on the computer.

4. Driver Installation:

  • If no new COM port was detected in the previous step, you may need to install the CH340 driver. You can obtain this driver from the TF card files or install the CH340 driver through the lasergrbl tool.

5. Baud Rate Setting:

  • Set the correct baud rate in the software, usually 115200.

6. Port Selection:

  • Select the correct COM port in the software. If you are unsure, try each available COM port.

7. Connection Operation:

  • Click the “Connect” button in the software to establish communication with the machine.

8.Troubleshooting:

  • If you still cannot connect after the above steps, restart your computer and repeat steps 5 to 7 without opening any other software. This helps to rule out the possibility of software conflicts.

9.Firmware Update:

  • If all steps have been tried and it still fails, and the software displays a prompt message on the left side of the dialog box, you may need to update the machine’s firmware. After updating the firmware, repeat the above steps.

Update Firmware Video Link

How to Deal with Distorted or Irregular Non-Closed Engraving Lines?

1. Adjustment of Pulleys and Tracks:

  • Use a wrench to slightly adjust the hexagonal column of the pulleys to ensure they are tightly attached to the tracks, moving smoothly without shaking.
  • After adjustment, manually move the X and Y axes to ensure they can move smoothly on the tracks without any jamming.

2. Synchronous Belt Tension Setting:

  • Adjust the synchronous belts of the X and Y axes to an appropriate pre-tension state, which helps maintain the synchronization and precision of the mechanical movement.

3. Laser Module Fixation:

  • Check and ensure that the screws fixing the laser module are firmly tightened, with no looseness, to avoid unnecessary shaking during operation.

4. Motor Function Verification:

  • To verify whether the motors on both sides of the Y-axis are working properly, you can first unplug the motor wire on one side, then use the software to control the movement of that axis for testing.

5. Operating Speed Adjustment:

  • Appropriately reduce the operating speed of the machine, especially after fine operations or adjustments, to ensure the stability and safety of the processing process.

6. Wheel and Track Inspection:

How to Deal with Inability to Cut?

1. Material Identification:

  • First and foremost, understanding the material of the item to be cut is crucial. Common cutting materials include plywood with a thickness of less than 3mm. Solid wood, acrylic plates, and other materials require low-speed cutting. Metal materials cannot be cut by a laser. (Refer to 1.png in the link)

2。 Cleaning the Laser Module:

  • After turning off the machine power, check whether the lens at the bottom of the laser module is dirty. Please gently wipe the laser lens with a cotton swab to ensure it is spotless. After cleaning, conduct a new engraving test to verify if the lens is clean (refer to whether the spot is normal). (Refer to 2.jpg in the link)

3. Software Settings Check:

  • When loading a design in the laserGRBL software, please check if the S setting value is sufficient. It is recommended to set the maximum S value to 1000, then perform the engraving test again. (Refer to 3.png in the link)

4. Power Setting:

  • In the “type gcode here” input box of the laserGRBL software, enter $30=1000, then press the “Enter” key on the keyboard. This will set the default maximum power level of the laser to 1000. Afterward, please attempt the engraving test again. (Refer to 4.png in the link)

5. Cutting Mode Selection:

  • When using the laserGRBL software to select M3 mode, the Lightburn software should enable “Constant Power Mode.” This is the mode suitable for cutting. (Refer to 5.1png and 5.2png in the link)

6. Speed Adjustment:

  • Appropriately reduce the engraving speed and try different speed settings. Since the density of the same thickness plywood may vary, it is necessary to adjust the speed according to the actual situation.

7. Laser Head Focus Adjustment:

  • Re-adjust the distance between the laser head and the object to be engraved according to the manual. Incorrect focusing may lead to the inability to cut. It is suggested to try different distances to see if there is any improvement. (Refer to the focusing method in the link)

8. Problem Diagnosis:

  • If the above steps do not resolve the issue, please project the laser onto a wall in an unoccupied area and take a photo for the record. Also, wear laser protective goggles to ensure safety. In addition, please take a photo of your engraved item and send it to us so that we can better assist you in diagnosing the problem.

Illustration Link

How to Deal with Layering Errors in the Engraved Pattern?
  1. Adjust the hexagonal column of the pulley with a wrench to ensure the wheel conforms to the track, moving smoothly without shaking. Also, ensure the X and Y axes move without getting stuck.
  2. The synchronous belts of the X and Y axes should be adjusted to a pre-tensioned state.
  3. The screws that fix the laser module must be firmly secured and not wobble.
  4. Check whether the motors on both sides of the Y-axis are working properly; you can unplug the motor wire on one side for verification.
  5. Reduce the operating speed appropriately.
  6. Inspect whether the wheels show signs of wear or if there are any foreign objects in the tracks.
  7. If the above steps do not resolve the issue, refresh the machine’s firmware. (The machine models in the links may vary, but the operation method is the same)
  8. If the ambient temperature is high, use a fan for cooling around the mainboard.
How to Deal with the Carving Process Being Interrupted Suddenly?

1. Change USB Port:

  • If you encounter connection interruptions, try changing the USB port on your computer. A loose connection or insufficient voltage may lead to unstable connections.

2. USB Cable Management:

  • Ensure that the USB cable is placed where it will not be touched or pulled. Improper cable management, such as accidentally pulling the USB cable, can also lead to connection interruptions.

3. Adjust Software Settings:

  • In the laserGRBL software, check the “Threading Mode” settings and select a lower-speed mode to improve stability. (Refer to 3.1png and 3.2png in Link 1)

4. Update Machine Firmware:

  • If the above steps do not resolve the issue, you may need to update the machine’s firmware. (Refer to the video in Link 2)
  • Please note that although the machine firmware in the video may differ from your machine, the steps to update the firmware are consistent. Please contact us to obtain the firmware suitable for your machine.

Illustration Link

Firmware Update Video Link

How to calibrate the focus before engraving?

1. Prepare the Focusing Post：

  • Ensure that the focusing post you are using is suitable for your machine and the material thickness. Focusing posts typically have different scales or steps to assist in adjusting the focus of the laser head.

2. Place the Focusing Post：

  • Place the focusing post between the surface of the engraving object and the machine’s adjustment block, ensuring that the focusing post is stable and perpendicular to the worktable.

3. Adjust the Z-Axis Lift Module：

  • Operate the Z-axis lift module, which is usually done through the machine’s control panel or software interface.
  • Adjust the Z-axis slowly until the laser head descends and makes contact with the first step of the focusing post.

4. Precise Focusing：

  • When the laser head makes contact with the first step of the focusing post, stop further descent.
  • At this point, the laser focus should be precisely on the surface of the engraving object.

5. Conduct a Test：

  • Before starting the actual engraving, it is recommended to do a test to ensure the accuracy of the focus.
  • Observe the size and clarity of the laser spot on the surface of the object, and make minor adjustments to the Z-axis position if necessary.

-Focusing video

Laser Cutting Focus Adjustment Steps

1. Determine the Focus Position：

  • Before starting the cutting process, make sure that the laser’s focal point is exactly at the midpoint of the material’s layer; this step is essential for obtaining a precise and clean cut.

2. Adjust the Focus According to Material Thickness：

  • Different material thicknesses require different focus positions. You need to adjust the height of the Z-axis according to the thickness of the material to ensure the focus is correct.

3. Different material thicknesses require different focus positions. You need to adjust the height of the Z-axis according to the thickness of the material to ensure the focus is correct:

  • Using the different scales on the fixed focus column allows for a quick adjustment to the focus position suitable for materials of varying thicknesses.。

4. Focus Settings for Specific Material Thicknesses：

  • For materials that are 2mm thick, adjust the Z-axis so that the laser head aligns with the second step marking on the fixed focus column.
  • For materials that are 4mm thick, adjust the Z-axis so that the laser head aligns with the third step marking on the fixed focus column.
  • For materials that are 6mm thick, adjust the Z-axis so that the laser head aligns with the fourth step marking on the fixed focus column.

5. Safety Precautions：

  • When adjusting the Z-axis and operating the laser cutting machine, always follow safety procedures and wear appropriate protective equipment, such as laser safety goggles.

6. Test Cutting：

  • Before proceeding with the final cut, perform a test cut to check whether the focus position has resulted in the desired cutting effect.

TTS-20 Pro

How to Deal with the Machine Not Connecting to the Computer?

1. Power On Check:

  • Ensure that the laser engraving machine is powered on and that the fan of the laser module is rotating to confirm that the machine is working properly.

2. USB Connection Confirmation:

  • Please confirm that the USB cable is correctly connected to the machine’s interface.

3.Computer Recognition Check:

  • Check if your computer can recognize the machine’s COM port signal. If necessary, try using another USB port on the computer.

4. Driver Installation:

  • If no new COM port was detected in the previous step, you may need to install the CH340 driver. You can obtain this driver from the TF card files or install the CH340 driver through the lasergrbl tool.

5. Baud Rate Setting:

  • Set the correct baud rate in the software, usually 115200.

6. Port Selection:

  • Select the correct COM port in the software. If you are unsure, try each available COM port.

7. Connection Operation:

  • Click the “Connect” button in the software to establish communication with the machine.

8.Troubleshooting:

  • If you still cannot connect after the above steps, restart your computer and repeat steps 5 to 7 without opening any other software. This helps to rule out the possibility of software conflicts.

9.Firmware Update:

  • If all steps have been tried and it still fails, and the software displays a prompt message on the left side of the dialog box, you may need to update the machine’s firmware. After updating the firmware, repeat the above steps.

Update Firmware Video Link

How to Deal with the Engraved Pattern Being Inverted?

1. Axis Movement Test:

  • First, manually move the X and Y axes and carefully observe whether their movement directions are as expected.
  • If the movement direction is incorrect, open the LaserGRBL software, enter $RST in the “type gcode here” input box, and then press the “Enter” key on the keyboard. This will reset the machine to its default settings. Afterwards, please conduct movement and engraving tests again to verify if the problem has been resolved. (Refer to 1.png in Link 1)

2. Firmware Update:

  • If the problem still persists after the above steps, you may need to update the machine’s firmware. (Refer to the video in Link 2)
  • Please note that although the machine firmware shown in the attached video may differ from your machine, the steps to update the firmware are universal. Please contact us to obtain the firmware suitable for your machine model and follow the video guidance to update.

Illustration Link

Firmware Update Video Link

How to Deal with the Engraved Pattern Edges Turning Black?

1. Enable Engraving Mode:

  • In the LaserGRBL software’s “type gcode here” input box, enter $32=1, then press the “Enter” key on the keyboard. This will enable the engraving mode, preparing for the upcoming engraving work. (Refer to 1.png in Link 1)

2. Select Engraving Mode:

  • In the LaserGRBL software, select the M4 mode. Also, in the Lightburn software, make sure to turn off “Constant Power Mode”.
  • The M4 mode is specifically designed for engraving and is more suitable for fine engraving work. (Refer to 2.png and 2.2png in Link 1)

3. Firmware Update:

  • If the problem persists after following the above steps, you may need to update the machine’s firmware. (Refer to the video in Link 2)
  • The attached video shows the general steps for updating the firmware, although the firmware for different machines may vary, the update process is similar.
  • If your machine’s firmware is not included in the attachment, please contact us, and we will provide the firmware suitable for your machine.

Illustration Link

Firmware Update Video Link

How to Deal with the Inability to Achieve Grayscale Effects in Engraving?

1. Enable Engraving Mode:

  • In the LaserGRBL software’s “type gcode here” input box, enter $32=1, then press the “Enter” key on the keyboard. This will enable the engraving mode, preparing for the subsequent engraving tasks. (Refer to 1.png in the link)

2. Select Engraving Mode:

  • In the laserGRBL software, choose the M4 mode. Also, in the Lightburn software, ensure to disable “Constant Power Mode”.
  • The M4 mode is suitable for engraving as it offers finer control, making it ideal for engraving operations. (Refer to 2.png in the link)

3. Set Minimum Power:

  • In both laserGRBL and Lightburn software, ensure that the minimum power S value does not exceed 10% to prevent over-engraving or material damage. (Refer to 3.png in the link)

4. Choose Grayscale Mode:

  • In the Lightburn software, set the image mode to grayscale. Grayscale mode can help you control the engraving depth and power more precisely, leading to better engraving results. (Refer to 4.png in the link)

Illustration Link

How to Deal with the Machine Not Starting?

1. Check Power Connection:

  • Ensure that the adapter or power cord is correctly connected and that the power indicator light is on, indicating that the machine has power.

2. Test Power Switch:

  • Press the machine’s power switch repeatedly and observe if there are any changes or responses to determine if the machine can start normally.

3. Remove TF Memory Card:

  • Try removing the TF memory card and then power on again to rule out any startup issues that the memory card might cause.

4. Disconnect Laser Module and Motor Cables:

  • Unplug the cables of the laser module and all motors to disconnect them from the machine, then try to power on again.
  • If the machine can start successfully, then reconnect the cables one by one and observe the machine’s response.
  • If the machine shuts down again after plugging back a certain cable, this may indicate that there is an issue with the cable that was just reconnected.

5. Inspect the Control Box:

  • Open the control box and check if the switch wires are securely connected, without any detachment or damage.

6. Adapter Replacement Test:

  • If the above steps do not resolve the issue, try using another adapter of the same specification for a replacement test to determine if the problem is caused by the adapter.

TS1 Mini

What materials can be engraved?

Can be engraved wood, paper, scratch paper,kraft paper, acrylic,slate,ceramic, glass, coated metal,rubber,silicone,leather,lacquered metal,plastic, bamboo and other materials.

How to deal with pattern split-layer after carving?
  1. Adjust the hexagonal column of the pulley with a wrench to ensure the wheel conforms to the track, moving smoothly without shaking. Also, ensure the X and Y axes move without getting stuck.
  2. The synchronous belts of the X and Y axes should be adjusted to a pre-tensioned state.
  3. The screws that fix the laser module must be firmly secured and not wobble.
  4. Check whether the motors on both sides of the Y-axis are working properly; you can unplug the motor wire on one side for verification.
  5. Reduce the operating speed appropriately.
  6. Inspect whether the wheels show signs of wear or if there are any foreign objects in the tracks.
  7. If the above steps do not resolve the issue, refresh the machine’s firmware. (The machine models in the links may vary, but the operation method is the same)
  8. If the ambient temperature is high, use a fan for cooling around the mainboard.
How to Deal with the Machine Not Connecting to the Computer?

1. Power On Check:

  • Ensure that the laser engraving machine is powered on and that the fan of the laser module is rotating to confirm that the machine is working properly.

2. USB Connection Confirmation:

  • Please confirm that the USB cable is correctly connected to the machine’s interface.

3.Computer Recognition Check:

  • Check if your computer can recognize the machine’s COM port signal. If necessary, try using another USB port on the computer.

4. Driver Installation:

  • If no new COM port was detected in the previous step, you may need to install the CH340 driver. You can obtain this driver from the TF card files or install the CH340 driver through the lasergrbl tool.

5. Baud Rate Setting:

  • Set the correct baud rate in the software, usually 115200.

6. Port Selection:

  • Select the correct COM port in the software. If you are unsure, try each available COM port.

7. Connection Operation:

  • Click the “Connect” button in the software to establish communication with the machine.

8.Troubleshooting:

  • If you still cannot connect after the above steps, restart your computer and repeat steps 5 to 7 without opening any other software. This helps to rule out the possibility of software conflicts.

9.Firmware Update:

  • If all steps have been tried and it still fails, and the software displays a prompt message on the left side of the dialog box, you may need to update the machine’s firmware. After updating the firmware, repeat the above steps.

Update Firmware Video Link

Calibration guide

Laser Head Focusinginstructions:
Place the object to be engraved flat on the workbench and place thesupplied black focus card over it and ensure you wear goggles to protect your eyes. Adjust thefocus of the laser head to
the finest point, if the focus is not fine enough, engraving may not bepossible or the resultmay be unsatisfactory.

  1. Rotate the focuser left or right to minimise the focus/point of light,the smaller the focus the higher the accuracy and thebetter the result.
  2. Optimal focal length: 25-65mm.
  3. The best effect is when the engraved object is 25-65mm away fromthe bottom end ofthe laser head.
  4. Re-adjustment of the laser focus is required when engraving objectsof different heights.

TS2-10W

The engraved lines are distorted or not round or closed, how to handle?
  1. Adjust the fit between the pulley and the track: Use a wrench to slightly adjust the hexagonal column of the pulley to ensure that the wheel fits tightly with the track, runs smoothly without shaking. At the same time, ensure that the X-axis and Y-axis do not get stuck when moving.
  2. Adjust the tension of the timing belt: The timing belts of the X-axis and Y-axis should be adjusted to an appropriate preload state to ensure transmission efficiency and reduce slipping. Specific adjustment methods can refer to related video tutorials.
  3. Ensure the laser module is securely fixed: Check and ensure that the screws fixing the laser module are tightened in place to avoid any looseness, ensuring the stability of the laser module during operation.
  4. Reduce the machine’s operating speed appropriately: To improve the precision and quality of engraving or cutting, it is recommended to appropriately reduce the machine’s operating speed.
  5. Check the wheels and tracks: Regularly check if the wheels show signs of wear and whether there are anyforeign objects in the tracks. These factors can affect the smooth operation and accuracy of the machine.
Machine cannot connect to the computer, how to handle?
  1. Ensure the machine is powered on. (Check if the laser module fan is rotating normally)
  2. Ensure the USB data cable is connected to the machine’s USB port.
  3. Check if the computer can correctly recognize the machine’s COM port. (If it cannot be recognized, try changing to another USB port on the computer)
  4. If the computer does not recognize a new COM port, you will need to install the CH340 driver. The driver can be obtained from the TF card files or installed through the LaserGRBL tool.
  5. Set the correct baud rate in the software, choose 115200.
  6. Select the correct COM port in the software. (You can try testing all available COM ports one by one)
  7. Click the “Connect” button on the software interface.
  8. If the above steps still cannot successfully connect, try restarting the computer and then re-execute steps 5-7. (It may be caused by software conflicts)
  9. If the problem is still not resolved, and the software’s left dialog box displays an error message, you may need to update the machine’s firmware. After updating the firmware, please repeat the above steps.
Cannot start the machine, how to handle?
  1. Check the power connection: Please ensure that the adapter or power cord is correctly connected and that the power indicator light is on, indicating that the device is powered.
  2. Test the power switch: Press the machine’s power switch repeatedly to observe if there are any changes or responses to determine if the switch is working properly.
  3. Restart the device: Turn off the machine, remove the TF memory card, then turn it back on to rule out issues that may be caused by the memory card.
  4. Disconnect component connections: Unplug the cables of the laser module and all motors one by one, disconnecting them from the machine, then try to turn on again. If the machine can be turned on at this point, please plug the cables back in one by one in order. If the machine turns off again after plugging in a certain cable, there may be a fault with that cable.
  5. Check the control boardbox: Open the control board box and check if the switch wire is firmly connected, without detachment or damage.
  6. Replace the adapter for testing: If possible, try using another adapter of the same specification to rule out the device not working properly due to adapter issues.
The pattern is offset after engraving, how to handle?
  1. Adjust the fit between the pulley and the track: Use a wrench to slightly adjust the hexagonal column of the pulley to ensure that the wheel fits tightly with the track, runs smoothly without shaking. At the same time, ensure that the X-axis and Y-axis do not get stuck when moving.
  2. Tension adjustment of the timing belt: The timing belts of the X-axis and Y-axis should be adjusted to an appropriate preload state to ensure transmission efficiency and reduce slipping.
  3. Check the fixation of the laser module: Check and ensure that the screws fixing the laser module are tightened in place to avoid any looseness, ensuring the stability of the laser module during operation.
  4. Check the couplers of the Y-axis motor: Check whether the couplers on both the left and right sides of the Y-axis motor are working properly, ensuring there is no asynchronous movement due to loosened top screws.
  5. Adjust the running speed: To improve the precision of engraving or cutting, it is recommended to appropriately reduce the machine’s running speed.
  6. Check the wheels and tracks: Regularly check if the wheels show signs of wear and whether there are any foreign objects in the tracks. These factors can affect the smooth operation and accuracy of the machine.
  7. Firmware update: If the above steps do not solve the problem, it is recommended to refresh the machine’s firmware to ensure the best compatibility between software and hardware.
  8. Heat dissipation measures: In environments with high temperatures, please use a fan around the main control box for heat dissipation to protect the machine from overheating damage.
The machine’s emergency stop switch does not work, how to solve it?
  1. Dismantle the mainboard control box and check if the wiring of the emergency stop switch has fallen off or is damaged.
  2. Short circuit the power interface on the mainboard to check if the machine can be normally started. If it can, it indicates that the emergency stop switch is damaged.
The TS2 10W laser engraving machine uses an automatic focus on the Z-axis.

1. Laser Module Elevation Operation:

  • The laser module’s elevation device will move downward to allow the laser probe to approach the engraving surface.

2. Probe Contact and Z-Axis Limit Switch:

  • When the probe touches the engraving surface, the Z-axis limit switch is triggered, which is an automatic detection mechanism to ensure that the laser module does not descend too low.

3. Laser Module Returns to Pre-set Height:

  • After the limit switch is triggered, the laser module will automatically move upward to the elevation height preset by the user in the software.

4. Auto Focus Completion:

  • Once the elevation height is set, the machine will automatically complete the focusing process to ensure a constant distance between the laser module and the engraving surface.

5. Relationship between Elevation Height and Focal Length:

  • For example, if the elevation height is set to 7mm, when the laser module moves upward by 7mm, the focal length (i.e., the distance from the laser module to the engraving surface) will be set to 50mm.

6. Importance of Focal Length Setting:

  • Correct focal length setting is crucial for the quality of laser engraving and cutting, affecting the concentration of laser energy and the processing effect.

7. Software Settings:

  • Users need to correctly set the elevation height in the control software of the laser engraving machine to ensure that the laser module can focus correctly on different materials and thicknesses.

Autofocus tutorial

TS2-20W

Machine cannot connect to the computer, how to handle?
  1. Ensure the machine is powered on. (Check if the laser module fan is rotating normally)
  2. Ensure the USB data cable is connected to the machine’s USB port.
  3. Check if the computer can correctly recognize the machine’s COM port. (If it cannot be recognized, try changing to another USB port on the computer)
  4. If the computer does not recognize a new COM port, you will need to install the CH340 driver. The driver can be obtained from the TF card files or installed through the LaserGRBL tool.
  5. Set the correct baud rate in the software, choose 115200.
  6. Select the correct COM port in the software. (You can try testing all available COM ports one by one)
  7. Click the “Connect” button on the software interface.
  8. If the above steps still cannot successfully connect, try restarting the computer and then re-execute steps 5-7. (It may be caused by software conflicts)
  9. If the problem is still not resolved, and the software’s left dialog box displays an error message, you may need to update the machine’s firmware. After updating the firmware, please repeat the above steps.
Laser head does not emit light, how to handle?
  1. Ensure the machine has successfully connected to the computer’s LaserGRBL software. If not successfully connected, the laser module will not be able to emit a laser.
  2. Check if the motor cables are correctly installed. If necessary, please reinstall the cables to ensure they are connected properly. After correct connection, the fan on the laser module should rotate normally.
  3. If the fan does not rotate, open the main control box and check if there is any cable detached from the laser interface “S-TTL-V”. If there is any detachment, please reconnect the cables.
  4. If the fan is rotating normally, further check if the cable at the “S-TTL-V” interface is conductive. Only conductive cables can control the laser emission. If the cable is damaged, please notify us for replacement.
  5. After confirming that the cables and fan are normal, please perform the following steps:
  6. If the above steps do not resolve the issue, please try to update the firmware of the machine.
  7. Control the laser to emit light within the software and engrave a square with dimensions of 300mm by 300mm. Observe whether the laser abnormally brightens in a specific area. If so, this may indicate that there is damage to the laser wiring, leading to poor contact.
Laser light intensity is very weak and cannot engrave wood, how to handle?
  1. Check the S setting value in the LaserGRBL software: Make sure that the S value (indicating laser power) is sufficient when loading the design. Set the maximum S value to 1000, then retest the engraving.
  2. Set the maximum laser power in the LaserGRBL software: Enter the command $30=1000 in the “type gcode here” input box, then press “Enter”. This sets the default maximum laser power to 1000. Retest the engraving afterward.
  3. Clean the laser module lens: Turn off the machine power and check for dirt on the lens at the bottom of the laser module. Gently wipe the lens with a cotton swab to ensure it’s spotless, then retest the engraving.
  4. Adjust the engraving speed: Reduce the engraving speed appropriately, for wood, a recommended speed is about 3000mm/min (note it’s millimeters per minute, not per second). Adjust the speed according to the actual situation.
  5. Adjust the distance between the laser head and the object: Re-adjust the distance between the laser head and the object to be engraved according to the manual. If the focus is inaccurate, it may lead to poor engraving results. Try different distances to see if there is any improvement.
  6. If the problem is still not resolved: Please, in a safe and unattended environment, project the laser onto a distant wall and take a photo. Please wear appropriate protective glasses and pay attention to safety. Afterwards, send us the photo so we can further analyze the problem.
WiFi cannot connect, how to handle?

1. Pay attention to wireless frequency band compatibility:

  • Please ensure that your machine only connects to 2.4GHz frequency band wireless networks, as the machine is not compatible with the 5GHz frequency band.

2. Optimize wireless signal reception:

  • To ensure the effectiveness of the wireless signal, please place the machine close to the wireless signal source.

3. Verify wireless network settings:

  • Check whether the wireless network name (SSID) and password are correct.
  • If in doubt, try deleting the existing settings and then re-enter the correct network name and password.

4. Test with a different device:

  • If the problem still exists, it is recommended to use another device to try connecting to the same wireless network to determine whether the problem lies with the machine itself.

5. Simplify WiFi password:

  • To improve the connection success rate, it is recommended to set a simple and short WiFi password.

Video link 1

Uses an automatic focus on the Z-axis.

1. Laser Module Elevation Operation:

  • The laser module’s elevation device will move downward to allow the laser probe to approach the engraving surface.

2. Probe Contact and Z-Axis Limit Switch:

  • When the probe touches the engraving surface, the Z-axis limit switch is triggered, which is an automatic detection mechanism to ensure that the laser module does not descend too low.

3. Laser Module Returns to Pre-set Height:

  • After the limit switch is triggered, the laser module will automatically move upward to the elevation height preset by the user in the software.

4. Auto Focus Completion:

  • Once the elevation height is set, the machine will automatically complete the focusing process to ensure a constant distance between the laser module and the engraving surface.

5. Relationship between Elevation Height and Focal Length:

  • For example, if the elevation height is set to 7mm, when the laser module moves upward by 7mm, the focal length (i.e., the distance from the laser module to the engraving surface) will be set to 50mm.

6. Importance of Focal Length Setting:

  • Correct focal length setting is crucial for the quality of laser engraving and cutting, affecting the concentration of laser energy and the processing effect.

7. Software Settings:

  • Users need to correctly set the elevation height in the control software of the laser engraving machine to ensure that the laser module can focus correctly on different materials and thicknesses.

Autofocus tutorial

TS2-LaserGRBL import tutorial
  1. Open the TS2-LaserGRBL software, select the correct COM port to connect to the engraving machine, and then right-click the mouse in the control bar at the bottom of the software to start customizing commands.
  2. A pop-up editing page will appear; edit the commands according to the instructions.
  3. A pop-up editing page will appear; edit the commands according to the instructions
  4. After entering the name, save it, and then set the other commands in the same manner
  5. After setting the parameters, if you want to perform engraving, first click on ‘Carve’ to save the configuration, and then execute the Z-axis zeroing command
TS2-LightBurn Import tutorial
  1. Open the TS2-LightBurn software and select the correct COM port to connect to the engraving machine
  2. 2In the software, right-click the ‘Customize’ button in the upper right corner to enter the editing mode
  3. Set the Z-axis zeroing button
  4. Set the engraving button
  5. Set the cutting button

Matters needing attention：

  • After the machine guides the configuration file, the starting position needs to be changed to ‘Current Position’”.
  • At the same time, set the job origin to the lower left corner (A11).

TS2-LightBurn software auto focus import

Accessory assembly tutorial

Extension Kit 600*600mm
TR2 PRO Rotary
TS2 Extension Kit
1064 Laser Head Kit

The 1064 laser head is an expansion kit for a laser engraving machine. It has a higher wavelength and greater power, which provides better engraving effects on materials that are more difficult to work with.

3D Printer

SK1

No Response After Powering On the Machine, How to Handle It?

Troubleshooting Steps for 3D Printer Power-On Issues

1. Check Power Connection

  • Ensure the power cord is properly connected to the printer and that the power outlet is functioning correctly.
  • Try connecting the power cord to a different outlet to rule out the possibility of a power supply issue.

2. Check Power Switch

  • Confirm that the power switch is turned on.
  • If the boat switch light is on but the power indicator light is not, it may be due to incorrect wiring of the power lines or incorrect wiring of the boat switch, preventing power from being supplied. It is necessary to recheck and ensure the wiring is correct.
  • If the wiring is correct but the power indicator light is still not on, it may be that the power supply unit itself is faulty.

3. Check the Boat Switch

  • If the boat switch light is not on, it may be due to a blown fuse.
  • Check if the fuse has blown and consider replacing it with a spare fuse.

4. Check the Control Board

  • If possible, open the printer casing and carefully inspect the control board for any signs of damage or burnout.
  • If damage to the control board is found, it may be necessary to repair or replace it.
Extruder Clogging Issue

1. Material Clogging Due to High Printer Chamber Temperature

  • Reduce the Bed Temperature: Lower the bed temperature appropriately to prevent the material from overheating and becoming too soft.
  • Use Heat-Resistant Materials: Opt for filaments with a higher heat deflection temperature, such as PLA or PETG.
  • Enhance Cooling: If the printer is equipped with an enclosure kit, open the front door or top cover during printing to assist with heat dissipation.

2. Extrusion Gear Malfunction Causing Poor Extrusion

  • Test the Nozzle: Set the nozzle temperature to 240°C, insert PLA filament, and press the extrude button. Observe the extrusion of the filament. If the filament falls vertically smoothly and the strand is long and smooth, the nozzle and extrusion gear are functioning properly. On the contrary, if the strand is short and rough, it may indicate a narrow nozzle channel or extrusion gear malfunction.
  • Inspect the Nozzle and Extruder: Unscrew the nozzle, set the nozzle temperature to 220°C, and manually push in PLA filament. If the filament extrudes smoothly, the nozzle channel is clear; inspect the extruder gear for wear or blockages by foreign objects and replace or clean as needed.

3. Clogging Caused by Soft Filament

  • Avoid Soft Filaments: Certain soft filaments, such as TPU 85A or damp PVA, can be flattened by the extruder gears, leading to clogging. Avoid using these types of filaments for printing.

4. Filament Diameter Variation

  • Check Filament Diameter: Filament may become thicker locally after bending or compression, or thinner due to extruder wheel wear, affecting normal extrusion. Remove the filament, trim off the parts with abnormal diameter, and then proceed with printing.
How to Handle a Faulty or Noisy Fan in the Machine?

Operational Steps to Resolve 3D Printer Fan Noise Issues

1. Clean the Fan

  • Fans may produce noise due to the accumulation of dust or debris.
  • Gently clean the fan blades and surrounding area with compressed air or a soft brush to remove dust and debris.

2. Check the Bearings

  • Fan bearings may produce noise due to wear or damage.
  • Gently rotate the fan to check for any abnormal friction or noise.
  • If friction is felt, attempt to lubricate the fan bearings to reduce friction and eliminate noise.

3. Check the Mounting Screws

  • Ensure that the fan’s mounting screws are tightened and not loose.
  • Loose screws may cause the fan to vibrate and produce noise during operation.

4. Check Fan Integrity

  • Inspect the fan blades for cracks, bends, or other signs of damage.

5. Replace the Fan

  • If the above methods do not resolve the issue, it may be necessary to consider replacing the fan.
  • Replacing the fan can completely solve the noise issue caused by fan damage.
The Machine’s Nozzle or Heated Bed Temperature is Unstable, Leading to Poor Printing Quality

Temperature stability PID value calibration is required. Please watch the video tutorial.

Failure to Home X or Y Axis

Check if the machine’s guide rails are operating normally, and it is best to apply lubricant to the guide rails.

Z-axis Offset Calibration

3D Printer Z-Axis Offset Calibration Steps

Purpose:
Calibrating the Z-axis offset is crucial for adjusting the distance between the nozzle and the print bed, which directly affects the quality of the first layer print.

1: Inspect the Nozzle and Print Bed

  • First, inspect the printer’s nozzle and print bed to ensure both surfaces are clean, without any plastic residue or debris.

2: Prepare an A4 Paper

  • With the nozzle and heated bed at room temperature, prepare an A4 paper for calibration.

3: Initiate Z-Axis Offset Calibration

  • Click on the “Z-Axis Offset Calibration” option on the screen to prepare for calibration.

4: Perform Calibration

  • Place the A4 paper between the nozzle and the print bed.
  • Move the print bed up and down to adjust the Z-axis height.
  • Stop when there is a slight friction resistance felt between the paper and the nozzle as well as the print bed.

5: Determine and Record the Z-Axis Offset Value

  • Accept the current Z-axis height value; this value is the calibrated Z-axis offset obtained through calibration.

6: Apply the Calibration Value

  • Apply the obtained Z-axis offset value to the printer settings to ensure the precision of the first layer print.

By following these steps, you can ensure that your 3D printer’s Z-axis is accurately calibrated, leading to improved print quality and adhesion for the first layer of your prints.

SP-5 V3

TF Card Reading Issues

This section provides suggestions for troubleshooting issues related to the TF card or card reader of a 3D printer. Below is a refined version:

Steps to Resolve 3D Printer TF Card and Card Reader Malfunctions

1. Inspect the TF Card:

  • If the TF card is not functioning properly, start by formatting the card.
  • Formatting can clear potential file system errors or corrupted data.

2. Replace the TF Card:

  • If the issue persists after formatting, try using a new TF card for testing.
  • Replacing the TF card helps determine if the problem is caused by the card itself.

3. Check the Card Reader:

  • If the problem continues even after changing the TF card, the card reader may be faulty.
  • Try replacing the card reader to ascertain whether the issue lies with it.

4. Comprehensive Diagnosis:

  • After replacing both the TF card and the card reader, if the problem still exists, further inspection of the printer’s mainboard or other hardware components may be required.
Z-Axis Noise During Movement

3D Printer Z-Axis Lead Screw Maintenance and Inspection Steps

Maintaining the Z-Axis Lead Screw:

1. Clean Dust and Debris:

  • Regularly clean the Z-axis lead screw and guide rails of dust, debris, or plastic particles to maintain smooth movement and accurate positioning.

2. Apply Lubricant Evenly:

  • After cleaning, apply a layer of lubricating oil evenly on the Z-axis lead screw to reduce friction and extend its service life.

Inspecting the Z-Axis Lead Screw:

1. Inspect the Condition of the Lead Screw:

  • Carefully inspect the Z-axis lead screw for any signs of bending or deformation, as these issues may cause instability during the printing process.

2. Assess the Flatness of the Lead Screw:

  • If bending or deformation of the lead screw is detected, it may be necessary to correct or replace it to ensure smooth operation of the Z-axis and print quality.
The Machine’s Screen Shows White or Distorted Screen, How to Handle It?

3D Printer Display Malfunction Troubleshooting Steps

1. Power Off and Restart:

  • First, try turning off the printer and restarting it to see if the screen returns to normal display.

2. Reflash the Firmware:

  • If restarting is ineffective, attempt to reflash the printer’s firmware.
  • Firmware updates may resolve software conflicts or system errors and restore the screen display function.

3. Check Display Contact:

  • Remove the display from the printer’s casing and place it on an insulator.
  • Power on again to observe if the same problem occurs.

4. Diagnose the Cause of the Problem:

  • If the problem disappears after removing the display, consider adding an insulating pad between the display and the casing when reinstalling to avoid possible electrical interference.
  • If the problem persists, it could be that the display itself is damaged.

5. Replace the Display:

  • If it is determined that the display is damaged, a replacement or new display will be needed.

6. Install Insulating Material:

  • When reinstalling the display, if it is necessary to add insulating material to resolve the issue, refer to relevant video tutorials for the procedure.

Video link

The Machine Displays Negative Temperatures for the Extruder or Heated Bed After Powering On, How to Handle It?

If the thermistor wire of your machine is broken at the corresponding position, or it is not installed correctly on the mainboard, please follow these steps to handle it:

  1. Check for Breakage in the Thermistor Wire: Inspect the thermistor wire for any breaks or damage.
  2. Replace the Thermistor Wire If Broken: If you find that the wire is broken, replace it with a new thermistor wire.
  3. Ensure Proper Installation on the Mainboard: After replacing, carefully check and ensure that the thermistor wire is correctly inserted into the corresponding socket on the mainboard.
Hot End Damage

The hot end may experience damage, including thermistor breakage, heating block damage, and nozzle throat leakage. For these issues, component replacement is necessary.

The Machine Displays Negative Temperatures for the Extruder or Heated Bed After Powering On, How to Handle It?

If the thermistor wire of your machine is broken at the corresponding position, or it is not installed correctly on the mainboard, please follow these steps to handle it:

  1. Check for Breakage in the Thermistor Wire: Inspect the thermistor wire for any breaks or damage.
  2. Replace the Thermistor Wire If Broken: If you find that the wire is broken, replace it with a new thermistor wire.
  3. Ensure Proper Installation on the Mainboard: After replacing, carefully check and ensure that the thermistor wire is correctly inserted into the corresponding socket on the mainboard.

Accessory assembly tutorial

Enclosure Kit
SK1 Camera Kit
Have More technical questions? Please click here.

Migration & After - Sales

Migration

When will the official website start migrating?

From August 5th, 2025, the migration will start. The old official website will be gradually switched to the new platform.

Can the old domain name (such as https://www.twotrees3dofficial.com/) still be used?

The old domain names will be gradually phased out during the migration process.
For subsequent access, please directly visit the new official website: https://www.twotrees3d.com/

After - Sales

For products bought on the old official website, is the return & refund, exchange, and after - sales service still available?

After migrating to the new official website, users who purchased products on the old official website still enjoy return & refund, exchange, and after - sales services.

For users who placed orders on the old official website, which channel should they use for after - sales service?

Temporarily, you can contact the after - sales service team via the exclusive sub - domain: https://service.twotrees3dofficial.com/.You can also contact us directly through the new official website.

Which are the old domain names of the official website?

https://www.twotrees3dofficial.com/

https://de.twotrees3dofficial.com/

https://br.twotrees3dofficial.com/

https://fr.twotrees3dofficial.com/

https://cz.twotrees3dofficial.com/

The above are the old domain names that our official website has used. Users who placed orders on these websites can still enjoy our official after - sales services.

Have More technical questions? Please click here.
